A thermal cell works through three important steps during the PCR technique. The first step is denaturation, which occurs in the first cycle. From there, part to the following cycles to separate formed strands. While this occurs the temperature ranges between 94 and 98 º C. This process lasts at least 10 seconds.
The second step consists of the alignment of the firsts in the thread of the mold that you want to amplify. The passage lasts about 20 seconds and its temperature can become variable. This happens because it depends more than all of the firsts used in this operation. The firsts are small sequences of 20 nucleotides in which tests with simple sugars are used. On many occasions, glucose is part of it, the temperature used for this type of tests ranges between 55 and 65 º C, although some can reach up to 72 º C. This is the temperature suitable for working with Taq polymerase.
The third step is the elongation of the double strand of 20 pairs which has been created in the previous step. Elongation time should not be more than a minute by kilobase.
The YR01868 Thermal cycler is the flagship of Kalstein thermal cycling platform, offering unmatched...
The design of the independent module can help lab personnel utilize the intrument more efficiently and avoid...
Reliable guarantee for the accuracy of the temperature. Temperature extended control mode which is...
The most advanced semiconductor technology (Peltier based). No matter how you configure your YR01870 gradient ...
| Model | YR01871 |
| Block Formats | 96×0.2ml(A),54×0.5ml(B),96×0.2ml+77×05ml(C),384well(D) |
| Display Interface | 5.7’LCD |
| Max.Heating Ramp Rate | 4.0℃/s |
| Max.Cooling Ramp Rate | 3.5℃/s |
| Heating/Cooling adjustable rate | 0.1℃/s~4.0℃/s |
| Uniformity | ≤±0.2℃(20~75℃) |
| Accuracy | ≤±0.2℃ |
| Gradient Temp Range | 30~99℃ |
| Thermal Gradient Span | 2~30℃ |
| Gradient Uniformity | ≤0.2℃(single row) |
| Hot Lid Temp | 30~115℃ |
| Temp Control Mode | Block,tube |
| Memory Capacity | 200 |
| Max.No.of Cycle | 99 |
| Communication | USB2.0/RS 232 |
| Intelligent Diagnosis | – |
| Size(W×D×H,mm) | 380×270×250 |
| Weight(kg) | 7.2 |
The thermal cycler is a device that allows the polymerase chain reaction (PCR) efficiently and quickly; by means of the automatic and cyclical realization...
It is an apparatus that is used in molecular biology, allows to perform in an automated and sequential way...
A thermal cycler is a Molecular Biology Laboratory Equipment, used in the amplification of DNA molecules...
A thermal cycler or also called thermal sequencer is a laboratory equipment that allows to carry out the amplification...
A real-time thermocyclist is a specialized tool used in molecular biology laboratories to efficiently and quickly carry...
A real-time thermocycler is a molecular biology equipment widely used in the laboratories of this specialty....
The region became culturally distinguishable from the Lowlands from the later Middle Ages into the modern period...
In order to carry out the in vitro test of specific biological DNA samples, the Thermocycler, is aimed at the development and intervention in the discovery of basic molecules for life, together with DNA-related research, using the Polymerase Chain Reaction (PCR) ....
To know the price of PCR Thermocyclers we invite you to send us an email with your request through the contact form...
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
