The moisture analyzer is a device used to calculate the moisture content of virtually any substance. It performs, by analyzing the weight of the sample, heating it by means of halogen desiccator units. These units are reflected through the equipment, through percentages of moisture content, solid, weight and tolerance.
In general, the moisture content is determined by a thermogravimetric method, that is, loss by drying, by means of which the sample is heated and the weight loss is recorded, due to the evaporation of moisture. In this sense, the speed of desiccation is especially important, since it adapts to the needs of quality control and production. And thanks to the activity offered by the moisture analyzer, the determination of the samples to be studied is successfully obtained.
Halogen lamp/HBM sensor,Aluminum shell/Stainless steel chamber,LCD（White back light with black font)...
Aluminum shell/Stainless steel chamber,Real-time dynamic curve/Date and Tim,Temperature/Time set...
Polymer materials/Heat resistant molding,Dual motor drive/Double fan design,Temp.control/Stainless...
Aluminum shell/Stainless steel chamber,High definition LCD,Temperature/Time set,The percentage of moisture...
| Model | YR053481 |
| Capacity | 110g |
| Readability | 0.001g |
| Operating Temp | 5℃-35℃ |
| Display | LCD HD Back Display |
| Calibration | External Calibration |
| Interface | RS232(Standard) / USB(Optional) |
| Pan Size | Ø90mm |
| Packing Size | 490x350x360mm |
| Gross Weight | 7.5kg |
| Heating Source | Infrared Lamp |
| Temp. Sensor | PT100 |
| Temp. Range | 40℃-160℃ |
| Temp. Step | 1℃ |
| Moisture Range | 0.00%-100.00% |
| Moisture Readability | 0.01% |
| Dry Range | 100.00%-0.00% |
| Dry Readability | 0.01% |
| Temp Setting | 40℃-199℃ By 1℃ Step |
| Time Setting | 1-99min By 1s |
| Number Of Storage | 15 |
| Number Of History | 5 |
| Heater | 220V ±15% 50HZ/110V±15% 60HZ/400W |
| Balance | Input:220V 50HZ/110V 60HZ Output:9V |
The moisture analyzer basically works through integral devices, through special modules that calculate...
The drying processes for coffee production are the most used because it allows the conservation of grains...
The main objective of the care and maintenance of moisture analyzers, as drying processing equipment of the...
A moisture analyzer is a measuring device that establishes the moisture compensation of a sample. It works...
During the practice of moisture analyzers, it is of great importance, the functions according to the heating efficiency...
The moisture analyser, is a laboratory equipment designed to accurately determine the moisture content of any sample..
The moisture analyzers work to calculate the moisture content of the matter, have halogen and infrared heating...
The analysis of the quantities of water in the substances, to determine the moisture levels are necessary tests for registration and quality control test in the manufacture of the products. And moisture analyzers are the ideal laboratory equipment for such purposes...
To know the price of the Humidity Analyser we invite you to send us an email with your request through the contact form...
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
